GMB-750
●Specifications
| Units | GMB-750 | ||
| Pumping Speed 50/60Hz |
m3/h L/min |
625 / 750 10417 / 12500 |
|
|---|---|---|---|
|
Max. permitted pressure difference with suitable backing pump 50/60Hz |
Pa Torr |
8.0×103 / 6.7×103 60 / 50 |
|
| Motor power |
kw (poles) |
2.2 (2) | |
| Oil | MR-250 | ||
| Oil capacity | Litter | 1.3 | |
| Cooling water | Cooling method | water-cooled | |
| Flow rate | L/min | 3 | |
| Temperature | ℃ | 5 to 30° | |
| Suction port flange | Corresponds to ISO 100 | ||
| Exhaust post flange | Corresponds to ISO 100 | ||
| Weight | kgs | 145 | |
