GRV-100
1.Heavy duty construction, compact design, small footprint, air-cooled design, easy to install and maintenance
2.Direct drive without belt, low noise, low vibration, no need anchor bolts to fix
3.With a build-in high efficient filter, the oil mist was filtered out 99.9%.
4.Fitted Gas ballast valve to absorb gases containing water vapor.
5.Inlet check valve prevented the backflow of vacuum oil
6.The vane with high-tech material provided long vane life
●Technical Information
Specification / Model
GRV-100
pumping volume m³/h 50/60Hz
100 / 120
ultimate vacuum mbar
0.5
Motor Kw 50/60Hz
3.0 / 3.5
Spindle speeds r.p.m 50/60Hz
1450 / 1750
Power phase
3ph
Voltage~V
200~240V / 380~440V
Inlet inch PT
1 1/4"
Discharge inch PT
1 1/4"
Fuel injection liter
2.0
Noise dB(A)
77
Dimensions LxWxH mm
707x406x325
Net Weight Kgs
70
