DVP-52
Features：
‧Oil-free carbon steel vane. Without environmental pollution problem.
‧Gear belt transmission design
‧Isolated vacuum & pressure operation mode
‧Operating vacuum & pressure is adjustable.
‧With built-in filters at both of suction inlet & discharge outlet port.
‧Suitable for printing industry.
‧Oil-free carbon steel vane. Without environmental pollution problem.
‧Gear belt transmission design
‧Isolated vacuum & pressure operation mode
‧Operating vacuum & pressure is adjustable.
‧With built-in filters at both of suction inlet & discharge outlet port.
‧Suitable for printing industry.
●Features
‧ Oil-free carbon steel vane. Without environmental pollution problem.
‧ Gear belt transmission design
‧ Isolated vacuum & pressure operation mode
‧ Operating vacuum & pressure is adjustable.
‧ With built-in filters at both of suction inlet & discharge outlet port.
‧ Suitable for printing industry.
●Specifications for Combination Model
‧ The range of ambient operating temperature is between 0~40℃
‧ Dimension & weight included 3-phase motor
‧ Oil-free carbon steel vane. Without environmental pollution problem.
‧ Gear belt transmission design
‧ Isolated vacuum & pressure operation mode
‧ Operating vacuum & pressure is adjustable.
‧ With built-in filters at both of suction inlet & discharge outlet port.
‧ Suitable for printing industry.
●Specifications for Combination Model
| Model | DVP-52 | |
| Nominal speed (r.p.m.) | 1450 (50Hz) | 1750 (60Hz) |
|---|---|---|
| Discharge capacity (L/min) | 405 | 480 |
| Ultimate vacuum (mmHg) | -660 | |
| Continuous operative vacuum (mmHg) | Under -450 | |
| Continuous operative pressure (kg/cm²) | Under 0.6 | |
| Suction /Exhaust port | 3/4 PT | |
| Motor power 3phase | 1.5kw 4poles | |
| Dimensions (mm) (L×W×H) | 560×330×360 | |
| Weight (kgs) | 47 | |
‧ Dimension & weight included 3-phase motor
